Overview

  • Country/Region Bolzano Bozen, Italy
  • Latitude, Longitude 46.496, 11.338
  • Elevation 331.2 m

Station Information - BZR200ITA

  • Receiver - Firmware LEICA GR30 - 4.50/7.710
  • Antenna - Radome LEIAR25.R4 - LEIT
  • Antenna Calibration ROBOT
  • Clock INTERNAL
  • Last RINEX Data - Primary Data Center 2022-01-27 (v3) - BKG
  • Constellation - RINEX GPS+GLO+GAL+BDS
  • Constellation - RealTime GPS+GLO+GAL
  • DOMES Number 12751M003
  • Nearby Tide Gauge N/A
  • Station Log bzr200ita_20211119.log
  • Analysis Center Usage

    Final
    Rapid
    Ultra
    GFZ2022-01-21

Receiver & Antenna Changes

  • Receiver - Firmware
  • LEICA GR30 - 4.50/7.710 2021-06-16
  • LEICA GR30 - 4.31/7.403 2020-03-05
  • LEICA GR30 - 4.31/7.403 2020-01-23
  • LEICA GR30 - 4.31/7.403 2019-01-09
  • LEICA GR30 - 4.20/7.30 2018-02-13
  • LEICA GR30 - 4.11/7.102 2017-10-27
  • Antenna - Radome
  • LEIAR25.R4 - LEIT 2017-10-27

Email Advisories

The residual plots show the differences between weekly station position estimates (from the weekly IGS combined solutions) and the latest IGS cumulative solution piecewise linear [+post-seismic deformation] model. For more information on the IGS cumulative solution please see: https://webigs.ign.fr/tfcc/en/solution/cumulative

The position time series are extracted from the daily IGS SINEX solutions.
