Overview

  • Country/Region DIONYSOS, Greece
  • Latitude, Longitude 38.079, 23.932
  • Elevation 510.6 m

Station Information - DYNG00GRC

  • Receiver - Firmware SEPT POLARX5 - 5.5.0
  • Antenna - Radome TRM59800.00 - NONE
  • Antenna Calibration ROBOT
  • Clock INTERNAL
  • Last RINEX Data - Primary Data Center 2022-12-02 (v3) - IGN
  • Constellation - RINEX GPS+GLO+GAL+BDS+SBAS+IRNSS
  • Constellation - RealTime GPS+GLO+GAL
  • DOMES Number 12602M006
  • Nearby Tide Gauge RAFINA - 7773m
  • Station Log dyng00grc_20221130.log
  • Analysis Center Usage

    Final
    Rapid
    Ultra
    COD2022-11-26
    EMR2022-11-12
    ESA2022-12-03
    JPL2022-11-192022-11-26
    MIT2022-11-26
    USN2021-12-04

Receiver & Antenna Changes

  • Receiver - Firmware
  • SEPT POLARX5 - 5.5.0 2022-11-30
  • SEPT POLARX5 - 5.4.0 2021-11-10
  • SEPT POLARX5 - 5.3.2 2021-10-26
  • TRIMBLE NETR9 - 5.45 2020-06-03
  • TRIMBLE NETR9 - 5.43 2019-12-23
  • TRIMBLE NETR9 - 5.42 2019-10-24
  • TRIMBLE NETR9 - 5.37 2019-01-31
  • TRIMBLE NETR9 - 5.33 2018-08-02
  • TRIMBLE NETR9 - 5.30 2018-02-20
  • TRIMBLE NETR9 - 5.22 2017-07-31
  • TRIMBLE NETR9 - 5.15 2016-12-14
  • TRIMBLE NETR9 - 5.14 2016-07-05
  • TRIMBLE NETR9 - 5.01 2015-10-08
  • TRIMBLE NETR9 - 5.01 2015-06-19
  • TRIMBLE NETR9 - 4.85 2014-06-05
  • TRIMBLE NETR9 - 4.70 2013-05-31
  • TRIMBLE NETR9 - 4.60 2013-04-01
  • TRIMBLE NETR9 - 4.60 2012-06-08
  • TRIMBLE NETR9 - 4.42 2011-10-25
  • TRIMBLE NETR9 - 4.22 2011-05-12
  • Antenna - Radome
  • TRM59800.00 - NONE 2015-09-25
  • TRM59800.00 - NONE 2013-05-03
  • TRM59800.00 - NONE 2011-05-12

Email Advisories

The residual plots show the differences between weekly station position estimates (from the weekly IGS combined solutions) and the latest IGS cumulative solution piecewise linear [+post-seismic deformation] model. For more information on the IGS cumulative solution please see: https://webigs.ign.fr/tfcc/en/solution/cumulative

The position time series are extracted from the daily IGS SINEX solutions.
