Overview

  • Country/Region Greenbelt, United States of America (the)
  • Latitude, Longitude 39.021, -76.827
  • Elevation 17.9 m

Station Information - GODN00USA

  • Receiver - Firmware JAVAD TRE_3 DELTA - 4.1.01
  • Antenna - Radome TPSCR.G3 - SCIS
  • Antenna Calibration ROBOT
  • Clock EXTERNAL H2 Maser
  • Last RINEX Data - Primary Data Center 2022-12-02 (v3) - JPL
  • Constellation - RINEX GPS+GLO+GAL+BDS
  • Constellation - RealTime
  • DOMES Number 40451M127
  • Nearby Tide Gauge N/A
  • Station Log godn00usa_20220125.log
  • Analysis Center Usage

    Final
    Rapid
    Ultra
    COD2022-10-01
    EMR2022-11-26
    ESA2021-10-02
    GFZ2022-04-30
    MIT2022-11-26

Receiver & Antenna Changes

  • Receiver - Firmware
  • JAVAD TRE_3 DELTA - 4.1.01 2021-07-22
  • JAVAD TRE_3 DELTA - 4.0.02 2021-03-17
  • JAVAD TRE_3 DELTA - 3.7.9 2021-01-29
  • JAVAD TRE_3 DELTA - 3.7.9 2020-04-03
  • JAVAD TRE_3 DELTA - 3.7.6 2019-05-06
  • JAVAD TRE_3 DELTA - 3.7.2 2018-09-28
  • JAVAD TRE_3 DELTA - 3.6.4 2016-04-04
  • JAVAD TRE_3 DELTA - 3.6.3 2015-09-14
  • JAVAD TRE_G3TH DELTA - 3.5.5 2014-04-10
  • JAVAD TRE_G3TH DELTA - 3.4.12 2013-10-31
  • JAVAD TRE_G3TH DELTA - 3.3.13 2013-05-23
  • JAVAD TRE_G3TH DELTA - 3.3.5 2013-04-17
  • JAVAD TRE_G3TH DELTA - 3.4.7 2013-04-01
  • JAVAD TRE_G3TH DELTA - 3.3.5 2012-01-14
  • Antenna - Radome
  • TPSCR.G3 - SCIS 2012-01-14

The residual plots show the differences between weekly station position estimates (from the weekly IGS combined solutions) and the latest IGS cumulative solution piecewise linear [+post-seismic deformation] model. For more information on the IGS cumulative solution please see: https://webigs.ign.fr/tfcc/en/solution/cumulative

The position time series are extracted from the daily IGS SINEX solutions.
