IGS Station - HOFN00ISL

Overview

Country/Region Hoefn, Iceland
Latitude, Longitude 64.267, -15.198
Elevation 82.3 m

Station Information - HOFN00ISL

Receiver - Firmware LEICA GR50 - 4.50/7.710
Antenna - Radome LEIAR25.R4 - LEIT
Antenna Calibration ROBOT
Clock INTERNAL
Last RINEX Data - Primary Data Center 2023-03-29 (v3) - BKG
Constellation - RINEX GPS+GLO+GAL+BDS+IRNSS+SBAS
Constellation - RealTime GPS+GLO+GAL
DOMES Number 10204M002
Nearby Tide Gauge N/A
Station Log hofn00isl_20230209.log

Analysis Center Usage

	Final	Rapid	Ultra
COD		2023-03-30	2023-03-30
EMR		2023-03-09
ESA	2022-11-26
GFZ	2023-03-23
JPL	2023-03-02		2023-03-23
MIT	2022-11-26
NGS	2023-03-16	2023-03-30
SIO	2023-03-16	2023-03-23
WHU		2023-03-30

Receiver & Antenna Changes

Receiver - Firmware
LEICA GR50 - 4.50/7.710 2021-05-19
LEICA GR50 - 4.31/7.403 2019-06-13
LEICA GR50 - 4.31/7.403 2019-05-11
LEICA GRX1200+GNSS - 9.20/6.405 2018-12-05
LEICA GRX1200+GNSS - 8.51/6.111 2018-10-02
LEICA GRX1200+GNSS - 8.51/6.111 2018-06-12
LEICA GR25 - 3.11.1639/6.403 2014-11-03
LEICA GR25 - 3.10.1633/6.403 2014-09-11
LEICA GR25 - 3.10/6.403 2014-09-08
LEICA GR25 - 3.03/6.214 2014-02-18
LEICA GR25 - 3.01/6.212 2013-10-09
LEICA GR25 - 3.00/6.113 2013-05-05
TPS E_GGD - 2.6.1 JAN,10,2008 2010-03-30
TPS E_GGD - 3.4 DEC,12,2009 P2 2010-03-26
TPS E_GGD - 2.6.1 JAN,10,2008 2008-01-17
TPS E_GGD - 2.6.0 APR,18,2007 2007-09-23
TRIMBLE 4000SSI - 00729|00307|00334 2007-02-13
TRIMBLE 4000SSI - 00719|00304|00333 2004-10-11
TRIMBLE 4000SSI - 00729|00304|00333 1999-07-31
TRIMBLE 4000SSI - 7.12 1997-05-27

Antenna - Radome
LEIAR25.R4 - LEIT 2013-05-05
TPSCR3_GGD - CONE 2007-09-23
TRM29659.00 - NONE 2001-09-21
TRM22020.00+GP - DOME 2000-05-25
TRM22020.00+GP - DOME 2000-03-13
TRM22020.00+GP - DOME 1997-05-27

Email Advisories

Martin.Lier at bk Network Outage at Geodetic Observatory Wettzell - WTZA00DEU / HOBU00DEU / HOFN00ISL / NICO00CYP / WTZR2022/02/01
Uwe.Hessels at bk REYK00ISL,HOFN00ISL: Firmware update2021/05/19
Uwe.Hessels at bk HOFN: Stopping submission of Rinex2 data2020/10/20
Uwe Hessels WTZR, REYK, NICO, HOFN, ISTA: altered from MSM7 to MSM52019/09/27
Uwe Hessels WTZR, REYK, NICO, HOFN, ISTA: RTCM 3.x GNSS MSM7 and ephemeris activated2019/07/31
Uwe Hessels REYK, HOFN, OHI3, WTZ2: IRNSS added2019/06/19
hessels at fs.wet HOFN: receiver and meteo equipment exchange2019/05/11
hessels at fs.wet HOFN: planned outage2019/05/11
Uwe Hessels HOFN: Firmware update2018/12/05
Uwe Hessels HOFN: GR25 receiver replaced2018/06/13
Rudolf Stöge HOFN Data files DOY 232 from 00:00 UTC until 10:00 UTC are not available2016/08/19
Rudolf Stöge HOFN Submission of the missing daily data files DOY 351 and 3522015/12/21
Rudolf Stöge HOFN Firmware Upgrade from 3.10.1633/6.403 to 3.11.1639/6.4032014/11/04
Rudolf Stöge HOFN Resubmission of the daily data file DOY 2512014/09/24
Rudolf Stöge HOFN Firmware 3.10.1633/6.403 since DOY 253 00:00 UTC2014/09/11
Rudolf Stöge HOFN Upgrade of the firmware from 3.03/6.214 to 3.10/6.4032014/09/09
Rudolf Stöge BUCU, CONT, CONZ, HOFN, ISTA, LHAZ, NICO, ORID, PTBB, REYK, SOFI, WTZA, WTZR, WTZS, WTZZ, ZECK Resubm2014/06/17
Rudolf Stöge CONZ, CONX, HOFN, NICO, OHI2, OHI3, REYK, SOFI, WTZR, WTZS, WTZZ Antenna calibration files from Geo++2014/04/25
Rudolf Stöge HOFN Upgrade of the Firmware from 3.01/6.212 to 3.03/6.2142014/02/18
Rudolf Stöge HOFN Submission of the missing daily data file DOY 0252014/01/27
Rudolf Stöge HOFN Upgrade of the Firmware from 3.00/6.113 to 3.01/6.212 in the LEICA GR252013/10/11
Rudolf Stöge HOFN Submission of the missing daily data file DOY 2272013/08/22
Rudolf Stöge HOFN Replacement of the TPS E_GGD with a LEICA GR25 and of the TPSCR3_GGD with a LEIAR25.R4 / New ante2013/05/06
Rudi Stöger HOFN Data files DOY 242 from 00:00 UTC until 06:00 UTC are not available2012/08/31
Rudi Stöger HOFN Resubmission of the daily data file DOY 1942012/07/13
Rudi Stöger HOFN Resubmission daily data file DOY 1932012/07/12
Rudi Stöger HOFN Resubmission daily data files DOY 189, 190, 191 and 1922012/07/11
Rudi Stöger HOFN up again2012/07/06
Rudi Stöger HOFN Data gap2012/07/05
Rudi Stöger HOFN Resubmission of the daily data file DOY 1142011/05/11
Rudi Stöger HOFN Resubmission of the daily data file DOY 1292011/05/11
Rudi Stöger HOFN Data outage DOY 279, 2802010/10/07
Rudi Stöger ANKR, BUCU, CONT, , CONZ, HOFN, ISTA, LHAZ, NICO, OHI2, OHI3, , ORID, PTBB, REYK, SOFI, WTZA, WTZR, W2010/08/19
Rudi Stöger HOFN Resubmission of the daily data file DOY 0892010/04/01
Rudi Stöger HOFN Firmware Downgrade2010/03/31
Rudi Stöger HOFN Firmware Upgrade2010/03/26
Rudi Stöger HOFN Resubmission of the daily data file DOY 1782009/06/29
Rudi Stöger HOFN Resubmission of daily data file DOY 2892007/10/17
Rudi Stöger HOFN Resubmission of daily data file DOY 2882007/10/16
Rudi Stöger HOFN Resubmission of daily data file DOY 2842007/10/11
Rudi Stöger HOFN Resubmission of daily data file DOY 2832007/10/10
Rudi Stöger HOFN Resubmission of daily data files DOY 279, 280, 281, 2822007/10/10
Rudi Stöger HOFN Antenna Serial Number modified2007/10/01
Rudi Stöger HOFN Resubmission of daily data file DOY 1022007/04/13
Rudi Stöger HOFN Resubmission of daily data file DOY 0932007/04/04
Rudi Stöger HOFN Resubmission of daily data files DOY 089, 090, 091 and 0922007/04/03
Rudi Stöger HOFN Resubmission of daily data file DOY 0442007/02/14
Rudi Stöger HOFN Receiver replaced, data are available2007/02/13
Rudi_Stoeger HOFN Data day 285 resubmitted2004/10/12
Rudi_Stoeger HOFN Correction of the RINEX Headers days 283 and 2842004/10/11
Rudi Stöger HOFN Update Site Information2002/11/20
Rudi Stöger Update of the HOFN Site Information (new Format)2002/06/14
Rudi Stöger Antenna Replacement in HOFN 2001/09/24

The residual plots show the differences between weekly station position estimates (from the weekly IGS combined solutions) and the latest IGS cumulative solution piecewise linear [+post-seismic deformation] model. For more information on the IGS cumulative solution please see: https://webigs.ign.fr/tfcc/en/solution/cumulative

The position time series are extracted from the daily IGS SINEX solutions.
